Haitima 3/4" NBSW SS 3PC FSAS Ball Valve Double Acting Actuator
Product Code: HDA 2011KMD-34
...
Details
Approvals
ATEX, Fire Safe
End Connection
Socket Weld
Valve Material
Stainless Steel
Valve Working Temperature
-20°C to +220°C
Design
3 Piece
Size
3/4"
Brand
Haitima
Seal Material
Viton
Actuator Working Temperature
-20°C to +90°C
Valve Working Pressure bar
138
Function
Double Acting
Specification
3/4" Socket Weld, 3 Piece Ball Valve Fitted with a Pneumatic Actuator, Double Acting, ATEX, Fire Safe Approved, Stainless Steel Valve Material, Viton Seal Material, Valve Working Temperature -20°C to +220°C, Actuator Working Temperature -20°C to +90°C, Valve Maximum Working Pressure 138 bar, Haitima
Features: Stainless steel or carbon steel full bore direct mount ball valve. Available in BSPP, NPT, butt weld nominal boreor socket weld ends. Fire Safe approved and anti-static device (valve only). ATEX II 2GD c T5 certification. Haitima aluminium pneumatic actuator. Sized based on 10 bar pilot air and wet non-abrasive duty at +90°C.
Additional Variants
Product Name
Prod. Code
List
Discount
Buy
Line
Prod. CodeHDA 2011KMD-112List-Discount-Buy£560.25Line£560.25Available to Order
