M331-11485

Prisma Plastic PP10 Double Acting Actuator

Product Code: PP10



...

Details

Actuator Working Temperature
-32°C to +80°C
Air Consumption LPM Closing
0.45
Approvals
ATEX, SIL3
Brand
Prisma
Air Consumption LPM Opening
0.35
Valve Working Pressure bar
8
Actuator Material
Polyamide
Working Torque Nm
71
Rotation Angle
0-90°
Function
Double Acting

Specification

Double Acting Actuator, 0-90° Rotation Angle, ATEX, SIL3 Approved, Polyamide, 0.35 Litres per Minute Air Consumption Opening, 0.45 Litres per Minute Air Consumption Closing, 71 Torque Nm, Actuator Working Temperature -32°C to +80°C, Valve Working Pressure 8 bar, Prisma

Features: 0-90° rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 17 to 165.5 Nm at 6 bar. Single acting torques from 6.7 to 65.8 Nm end of spring. Polyamide body. ATEX II 2G Ex h IIC T6 Gb / II 2D Ex h IIIC T80°C Db certification. SIL3 rated. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.
