M310-01167

FT Pro 1/2" ID SAE 100R7 Hydraulic Hose 100R7

Product Code: 100R7-08-25



...

tech sheet 5011

Details

Hose Diameter (DN)
20.7
Maximum Working Pressure bar
140
Bend Radius mm
175
Brand
FT Pro
Outside Diameter mm
20.7
Length Metres
25
Colour
Black
Standard
SAE 100R7
Series
Cotton Braided
Working Temperature
-40°C to +93°C
Material
Polyurethane
Inside Diameter Inch
1/2"

Specification

20.7mm Outside Diameter x 1/2" Inside Diameter, Hydraulic Hose, 2 Yarn, Thermoplastic, 100R7, 25 Metre Coil, 175mm Bend Radius, Black, Polyurethane, Fibre Braid, SAE 100R7, Bursting Pressure 560 bar, Working Temperature -40°C to +93°C, Maximum Working Pressure 140 bar, FT Pro

Application: Thermoplastic hose with perforated coverr for use on medium pressure hydraulic applications. Specification: SAE100 R7. Construction: Inner tube: thermoplastic elastomer. Reinforcement: 2 single textile yarn braids. Outer coverr: high abrasion resistant polyurethane. Recommended fluids: Hose suitable for petroleum based hydraulic oil and water-glycol based fluids, lubricating oils, solvent and gas transfer. Available per 1 mtr
